eSSL Drop Bolt for Frameless Glass Door-10
- Description :
- Drop Bolt for Frameless Glass Door-10
- Brand :
- eSSL
- Features :
-
Suitable For - Glass Door
Current - 950mA
Bolt Size - 15.5mm diameter Stainless, Out throw 15mm
Magnet(L X W X H ) - 212 x 35 x 3mm
Armature Plate(L X W X H ) - 90 x 25 x3mm
Technical Specifications
- Working Voltage：DC：12V
- Working Current：12V：900mA±50mA
- Standby Current: 12V: 200mA±50mA
- Plate Material: Aluminum
- Plate Finishing: Anodization
- Working Feature: Fail Safe
- Working Temperature: -10～+55°C
- Working Humidity: 0～90%
- Bolt Diameter: 14.5MM
- Bolt Material: Aluminum
- Bolt Length: 15MM
- Face Plate: 145LX43WX38H (mm)
- Strike: 145LX43WX24H (mm)
- Time Delay: 0, 3, 6,9S
- Suitable for: Glass Door
